Are you considering laying your 12×20 shed on a skid foundation? You may wonder if it is good or not and probably how it works too.
It is normal to construct sheds on skid foundations. That is why knowing if your 12×20 shed can too is essential.
Building a 12×20 shed on the skids is very much possible, not to mention easy to construct. The 12×20 shed lies on a foundation of big timbers or long pieces of lumber, which makes the skids. The skid lays on the floor, and the floor frame is on the skids.
Ready for a Roofing Quiz?
Can you Drag a 12×20 Shed on Skids?
Absolutely! You can comfortably drag your 12×20 shed on the skids to anywhere you desire.
Building the shed foundation, which consists of long pieces of lumber, is very important because a shed on a skid foundation allows easy movement of the building.
The movement of the shed is done by connecting a tow rope or chain from the skids to the riding mower and then using the mower to pull to the desired destination.
When dragging your 12×20 shed on the skids, you should consider attaching slides under the skids. These slides allow for extreme ease while dragging your shed.
Since you can drag your sheds on the skids from one location to another, you’d agree that a skid foundation is advantageous in moving from one place to another.
How Much Would it Cost to Build a 12×20 Shed on Skids?
Building a 12×20 shed on the skids is highly dependent on many factors. These factors include location, the materials used, purpose, how finished you desire it to be, and the type of shed you want.
But the average cost of building a 12×20 shed on the skids is $20,000. The materials used are the highest determining factor for the cost of building this size of shed on the skids.
The table below has various materials and the average cost at which you can bet a 12×20 shed built on skids.
| Materials used | Cost of construction |
|---|---|
| Resin(Plastic) | $1000 |
| Metal | $5000 |
| Wood | $8,000 |
| Concrete | $20,000 |
| Brick | $25,000 |
There are other costs for building your 12×20 shed on skids, like the roof type. But the materials used are the highest determining factor.
The location is paramount, whereas the cost may differ and while constructing in a specific location costs more, constructing in other locations costs way less.
How do you Build a 12×20 Shed Floor on a Skid?
Below is a step-by-step guide to ensure the easy and proper construction of your 12×20 shed floor on a skid.
#1. Gather your Materials
The materials you’ll need are as follows;
- Wood screws and exterior grade screws
- Joist hangers
- Framing nails
- Pressure-treated lumber
- Pressure-treated plywood
#2. Layout the Area with Deck Block
After every 4-6 feet, lay a deck block to have equal distance from each other. Next, lay 2×6 boards in the grooves of the deck blocks.
Laying the wood in the grooves of the deck blocks gives the ground level and the floor frame stable support. Tap down and dig.
#3. Mark the Two-Band Boards
From the length and width of your 12×20 shed, ready two joists, and two rim joists. Ensure the rim joists’ length is the same as the shed’s length.
Cut your pressure-treated lumber with a chop saw according to your measurements. With a speed square, mark where your cuts need to be. Using a wood preservative, seal the cut ends of your lumber.
#4. Assemble the Outer Frame
Put the framing together and use framing nails to hold the ends. Join all four boards together to form a box.
#5. Square the Floor Frame Appropriately
Use a measuring tape to ensure you have an appropriate box with either every two sides equal or all four sides equal. Do not hesitate to move your blocks to make the perfect square.
#6. Anchor the Floor Frame
Using concrete piers, anchor your frame to keep it grounded. First, pick the areas where your anchors will be.
One anchor for every corner is perfect. Dig holes in those areas, fix the fiber tubules, add concrete, install the brackets and fix with anchors to the foundation.
#7. Place Rim Joists
Using a speed square, cut out rim joists to use. Fix the joists into the hangers and use a hammer to tap them down. Use the Simpson screws to attach joist hangers to the frame.
#8. Layout the Sheeting
Cut your plywood according to your desired length and width, which is 12×20. Ensure it is even, then you screw it down into the joists. Use two screws on each plywood at the edges where two pieces of the wood meet.
Do I Need a Permit for a Shed on Skids?
One advantage of having your shed on skids is that it doesn’t require a permit.
It doesn’t require a permit because you cannot class it as a permanent structure since you can move the shed from place to place, while other sheds with foundations other than the skid foundations require permits because they are permanent structures.
Although, it is better to call your local building inspector’s office to determine whether you need a permit.
A few areas may insist on you having a permit. Other areas insist that permits are necessary unless your shed is more than 10sq meters, where a permit is not essential.
That is why you should try to determine if a permit is necessary for your location or not.
It would be best if you tried contacting the local building inspector’s office as much as possible before you begin to construct your shed.
The inspectors of areas where permits are required are very strict with the rules. The officers may take actions like asking you to demolish your shed if you don’t have a permit or cease work on your shed and pay a fine of $600 or more.
Can Thinset be Used in a 12×20 Shed on Skids?
Thinset waterproof can be used in a 12×20 shed on skids. It is a versatile adhesive that ensures a strong bond between various materials, such as tiles and concrete. By using thinset waterproof, you can securely attach tiles to the shed floors or walls, providing a durable and water-resistant surface.
Does a 12×20 Shed need a Foundation?
A shed of 12×20 would require a stable foundation to stay balanced. Typically, any shed larger than 6×8 or 8×8 requires a foundation.
Building the shed foundation is essential as it allows proper water drainage, prevents premature weathering, and prevents damage to your shed.
Even if the shed is 6×8 or 8×8, getting a foundation for your shed should be your priority.
A good foundation is essential because sheds of that size are still very much prone to fall from the pressure of high winds or rainfall.
However, it is better to place all large or small sheds for structure and ventilation purposes.
A 12×20 shed without a foundation would hardly stand and could easily fall from the pressure exerted on it by strong winds. This fall is worse when you make your shed with plastic or light metal materials.
While constructing your 12×20 sized shed, building the shed foundation allows you to have the confidence of a long-lasting shed.
The best part is that you don’t need to call a service department to help build the shed foundation.
The process is relatively easy, and with suitable materials, a good guide, and a friend or two to help, you should have your foundation set in just one day.
Conclusion
Building a 12×20 shed on skids has many advantages like easy movement from place to place, no permits necessary, a solid and well-ventilated structure, and many more.
A skid foundation is easy to construct and requires very little help. Having your 12×20 shed on skids is a perfect option you should consider while constructing your shed.
